Original new ER13150 high capacity 3.6V small size primary Lisocl2 battery Manufacture
The ER13150 Lisocl2 battery is a non-rechargeable lithium battery with 3.6V small size high capacity 450mAh and is one of the lithium thionyl chloride batteries.
The ER13150 Lisocl2 battery is a non-rechargeable lithium battery with 3.6V small size high capacity 450mAh and is one of the lithium thionyl chloride batteries.
| Battery Description: |
Battery Model: | ER13150 | Battery Brand: | SER or OEM | |
Battery Capacity: | 450mAh ( at 0.5mA,under 25℃, 2.0V cut-off) | Dimension: | 13.5 x 15.7mm | |
Open Circuit Voltage: | ≥3.66V | Load Voltage: | ≥3.2V | |
Max continuous current | 10mA ( with 25℃, 2.0V cut-off) | Max Discharge current | 20mA(1s pulse to 3.0V) | |
Working temperature: | -55~+85℃ | Storage Life: | 10 years | |
Storage condition: | clean, cool (preferably below +20℃, not exceeding +30℃), dry and ventilated | |||
| Applications: | PLC system,ETC system,Alarm System,Utility Meters, real-time clock,CMOS board memory and backup power, data backup, smart meter, heat meter, electronic measuring instrument, real-time monitoring system, flow meter, tax control machine, GPS tracking system | |||
High light: | Original new ER13150 high capacity 3.6V small size primary Lisocl2 battery Manufacture Best ER13150 Li-SOCl2 Battery Energy Type non- rechargeable lithium battery supplier | |||
| Main Features: |
1. High Voltage,
The rated voltage is 3.6V, which is the highest voltage in the current non-rechargeable lithium battery series;
2. Stable working voltage
At room temperature and medium current discharge, the discharge curve is extremely flat and stable; more than 90% of the battery capacity is output on a high-voltage platform with almost constant voltage;
3. Wide temperature range
Can be used at temperature between -55°C ~ 85°C.The capacity at -40°C is about 50% of the standard capacity, showing excellent high and low temperature performance; High temperature range is -40～+150℃.
4. High energy density
The specific energy of lithium-thionyl chloride battery is as high as 700Wh/kgL
5. Better storage life and reliability
With particularly low self-discharge characteristics, less than 1% per year, and the shelf life of the battery has more than 10 years at room temperature.
6. Hermetic glass-to-metal sealing
The manufacturing process of stainless steel shell and metal-glass hermetic welded structure.
7. Good security, safety
Does not contain mercury, cadmium, lead and other heavy metals, Non-flammable electrolyte, no environmental hazards.
8. ER13150 Lithium Thionyl Chloride cell are available to order with a wide variety of solder pins, solder tags, axial wires,
and polarized solder Pin.
In all,The ER13150 Lisocl2 battery is a non-rechargeable lithium battery measuring 13.5 * 15.7 mm and is one of the ER series batteries. It has a high voltage of 3.6V and a high capacity of 450mAh, and the battery discharge voltage is very stable, and can work in high temperature and low temperature environment, and the performance is superior. These batteries are also very environmentally friendly because they do not contain heavy metals.
Warning:
Do not recharge, short circuit, crush, disassemble, heat above +125℃,
incinerate,or expose contents to water. Dispose of used batteries properly in case of explosion, burn and leakage.
| Applications: |
| Main applications: |
The ER13150 lithium battery has a wider operating temperature than other lithium-ion batteries, and is easy to store, has a very low self-discharge rate, and has high energy density and high voltage. Can be applied to portable GPS systems, power tools, cameras, smart meters and smart water meters.
a. Mainly used in the civil field: PLC system,ETC system,Alarm System,Utility Meters, real-time clocks
b. Various smart meters; smart electricity meters, water meters, heat meters, gas meters
c . Memory and backup power supply: memory backup, clock power supply, data backup power supply
d . Radio alarms/sensors: smoke alarms, temperature monitors
e . remote monitoring system: positioning device, marine telemetry system
f . Automotive electronics: automotive tire pressure monitoring system (TPMS), braking system
g. Industrial field: microcomputer control system, tax control machine, automated instrumentation and equipment, oil wells, mines, medical equipment, burglar alarms, wireless communications, marine lifesaving, etc.
h . Modern military fields: aviation, aerospace, marine electronics, amphibious weapons, etc.
i . AMR and CMOS circuit boards for public instruments
Non-Rechargeable (Primary) Lithium Thionyl Chloride Battery:
Energy-type Lithium Thionyl Chloride battery (including standard energy type and high-capacity type) generally works continuously for a long time with micro-current, and can provide medium-current pulses, and the working time can be as long as 8 years
Power-type Lithium Thionyl Chloride battery can be designed in different ways according to different uses. Generally, it mainly provides high current or high pulse current. At the same time, it can work continuously for a long time with low current, and the working time can reach 8 years;
High temperature Lithium Thionyl Chloride battery can be used in the temperature range of -40~125℃.
