Home > Products > LiSOCl2 battery
ER251020S
ER251020S
ER251020S battery

ER251020S 3.6V CC size high temperature battery for MWD tools

ER251020S 3.6V CC size high temperature battery for MWD tools

  • Model NO.：Er251020S
  • Voltage：3.6 V
  • Capacity：12000mAh
  • Shape：cylindrical
  • Battery Size：24.5*102mm
  • Brand：SER or OEM
  • Working temperature：-55~+150℃
  • Applications：MWD/LWD TOOLS, CONTAINER, TRACKING/MEDICAL DEVICE/TMPS SENSOR ETC.

Li-SOCL2 Batteries Catalogue(图1)

ER251020s,ER251020S battery,high temperature battery,cc size battery,high temperature battery CC size,LiSOCL2 battery,high temperature lisocl2 battery,high temperature battery ER251020S,MWD battery,LWD TOOLS battery

High temperature Battery ER251020S:


Recommended battery model parameters:


Battery model: High temperature battery ER251020S


Battery brand: SER


Battery performance index


1. Battery capacity: (23±2℃, 100mA/2.0V) 12000mAh


2. Open circuit voltage: ≥3.64V


3. Load voltage: (8Ω, 20±5℃, time ≤10s) ≥3.20V


4. Continuous working currents: (20±5℃) 100mA


5. Large pulse working current: (20±5℃) 200mA


6. Operating temperature range: -55~+150℃


7. Battery storage life: 10 years


High temperature battery ER251020S Advantages


Advantages:

1. High and stable operating voltage

2. Low self-discharge rate (less than 1% per year of storage at +25°C)

3. Wide range of operating temperature

4. Stainless steel container and end caps

5. Hermetic glass-to-metal sealing

6. Non-flammable electrolyte

7. Compliant with IEC86-4 safety standard, UL, CE, UN.


Related products:

ER10450S 0.5Ah      φ10.0×45.0mm 3511172_20231102141921697210_0.jpg


ER14250S 0.7Ah      φ14.5×25.0mm


ER14335S 1.0Ah      φ14.5×33.5mm


ER14505S 1.6Ah      φ14.5×50.5mm


ER17335S 1.7Ah      φ17.0×33.5mm


ER18505S 2.4Ah      φ18.5×50.5mm


ER26500S 4.5Ah      φ26.0×50.0mm


ER26102S 10Ah       φ26.0×102.0mm


ER34615S 12Ah       φ34.0×61.5mm


ER34127S 25Ah       φ34.0×127mm


  Applications




Main applications:

1. Exploration measurement instrument (mills,oil,fields)

2. Date reading instrument

3. electronic testing equipment

4. sea equipment

5. navigation and aviation equipment

6. Temperature Monitor and communcation equipment




              Company Advantage


















Li-SOCL2 Batteries Catalogue(图6)


ER18505M Power type 3.6V A size Primary Lisocl2 Batteries Flat Top Lithium Thionyl Chloride battery(图2)
ER18505M Power type 3.6V A size Primary Lisocl2 Batteries Flat Top Lithium Thionyl Chloride battery(图3)

With three producing bases, sixteen

advanced manufacturing lines, over

1650 staff, we can produce 20000,00

 cells and 600,000 rechargeable

battery packs per month.


Founded in 2004, Guangzhou Ser

Battery Technology Co.,Ltd is CE. UL.

SGS, IEC and ISO9001 certificated

High-tech company.


Customers' interests always goes

first,SER has a professional sales

team, shipping team and after

sales team to provide you with

the best solutions and timely service.









ER18505M Power type 3.6V A size Primary Lisocl2 Batteries Flat Top Lithium Thionyl Chloride battery(图4)
ER18505M Power type 3.6V A size Primary Lisocl2 Batteries Flat Top Lithium Thionyl Chloride battery(图5)

ER18505M Power type 3.6V A size Primary Lisocl2 Batteries Flat Top Lithium Thionyl Chloride battery(图6)

Efficient and innovative R & D team

helps the company lead in product

design and superior performance


While keeping core competitivenes,

SER also takes into account relevant

social, economic and environmental

goals, and always maintains sustained

profitability and development capabilities.


For many years, the professional
SER team has focused on the lithium
battery industry, and has taken every
product as a work of art with firmness,
steadiness and excellence.





Product Advantage

  1. Full range of battery categories

  17 years of development, SER have
  the ability to offer many product
  categories:Lisocl2 Battery, LiMNO2
  battery, LiPO battery and LiFePO4
  batteries.


  2. Safety

  The perfect protection IC has been used,
  undervoltage, short-circuit, overload,
  backflow,and we have carried out strict
  inspections and external tests, make sure
  no quality problems in the hands of
  customer.


 3. Excellent and stable performance

  Strict control for cleanliness in dust-free
  workshop from IQC,IPQC to OQC, we
  control every step strictly CE, UL, SGS,
  FCC,ROHS and ISO9001: 2000 certified.






  4. OEM & ODM Ability

  Professional engineers have rich
  experien ce in OEM& ODM. The
  independent labs have  many
  sophisticated machines and design
  softwares always guarantee our OEM
  &ODM projects always keep in
  high level.


  5. Technology

  Our dedicated and experienced engineers

  team always work together to our customers
  from their product design to battery solution
  and mass production,Reduce their time cost
  and communication cost.


  6. Delievry

  Fast delivery with standard package,will
  bring you a professional experience with
  long-term cooperative freight company
  and stable routes.
