ER34615 D LITHIUM BATTERY LR20 3.6V HIGH ENERGY LI/SOCL2 CELL D SIZE SINGLE NEW
ER34615 D LITHIUM BATTERY LR20 3.6V HIGH ENERGY LI/SOCL2 CELL D SIZE SINGLE NEWPrimary D Batteries ER34615 Lithium Thionyl Chloride battery high energy ER34615H
ER34615 D LITHIUM BATTERY LR20 3.6V HIGH ENERGY LI/SOCL2 CELL D SIZE SINGLE NEWPrimary D Batteries ER34615 Lithium Thionyl Chloride battery high energy ER34615H
Primary ER34615 D LITHIUM BATTERY LR20 3.6V HIGH ENERGY LI/SOCL2 CELL D SIZE SINGLE NEW
Primary D Batteries ER34615 Lithium Thionyl Chloride battery high energy ER34615H
| Battery Features: |
Recommended battery model parameters:
Battery model: D Size battery,LR20 batteries,ER34615,ER34615H
Battery brand: SER
Battery performance index
1. Battery capacity: (23±2℃, 2.0mA/2.0V) 19Ah
2. Open circuit voltage: ≥3.64V
3. Load voltage: (8Ω, 20±5℃, time ≤10s) ≥3.20V
4. Continuous working currents: (20±5℃) 200mA
5. Large pulse working current: (20±5℃) 400mA
6. Operating temperature range: -55~+85℃
7. Battery storage life: 10 years
| Eight Advantages |
The main raw materials are all imported from abroad, and the sealed lithium battery produced is novel in technology and has the following notable features andeight advantages:
1. The energy density is as high as 680Wh/kg, which is the highest among various lithium batteries.
2. High open circuit voltage: up to 3.66 volts for single battery& high working voltage, working voltage varies with load, usually between 3.3~ 3.6V
3. Low self-discharge rate: the annual self-discharge rate is less than 2%; the storage life can be 10-15 years at room temperature.
4. Wide temperature range: -55℃~+85℃.
5. The working voltage is stable: more than 90% of the battery capacity is output on a high-voltage platform with almost constant voltage.
6. The Li-SOCL2 battery is well sealed, safe and free of leakage.
7.Good safety record, pollution-free products fully meet the requirements of UL, CE, UN, do not contain mercury, cadmium, lead and other heavy metals, no environmental hazards.
Energy-type Lithium Thionyl Chloride battery (including standard energy type and high-capacity type) generally works continuously for a long time with micro-current, and can provide medium-current pulses, and the working time can be as long as 8 years
Power-type Lithium Thionyl Chloride battery can be designed in different ways according to different uses. Generally, it mainly provides high current or high pulse current. At the same time, it can work continuously for a long time with low current, and the working time can reach 8 years;
High temperature Lithium Thionyl Chloride battery can be used in the temperature range of -40~125℃.
APPLICATIONS
Applications:
Smart meter, water meter, heat meter, gas meter / • Smoke alarms, temperature monitors
• Intelligent Transportation (ETC) / • Ocean telemetry, positioning device
• Manhole cover protection, and road and bridge perception / • Utility Meter AMR
• Automotive electronics and anti-theft / • Oil well, mine detection and monitoring
• Underwater sonar, water buoys / • Military equipment, and individual equipment
| Company Advantage | |||||||
|  |  | |||||
With three producing bases, sixteen advanced manufacturing lines, over 1650 staff, we can produce 20000,00 primary cells and 600,000 rechargeable battery packs per month. | Founded in 2004, Guangzhou Ser Battery Technology Co.,Ltd is CE. UL. SGS, IEC and ISO9001 certificated High-tech company. | Customers' interests always goes first,SER has a professional sales team, shipping team and after sales team to provide you with the best solutions and timely service. | |||||
 |  |
| |||||
Efficient and innovative R & D team helps the company lead in product design and superior performance | While keeping core competitivenes, SER also takes into account relevant social, economic and environmental goals, and always maintains sustained profitability and development capabilities. | For many years, the professional | |||||
Product Advantage | ||||
1. Full range of battery categories 17 years of development, SER have | 2. Safety The perfect protection IC has been used, | 3. Excellent and stable performance Strict control for cleanliness in dust-free | ||
4. OEM & ODM Ability Professional engineers have rich | 5. Technology Our dedicated and experienced engineers team always work together to our customers | 6. Delievry Fast delivery with standard package,will | ||
